5300-ZZ, JAF/KYK Brand, 2-Row Angular Contact Ball Bearing (0324k)

$ 15.20

5300-ZZ, JAF or KYK Brand, 2-Row Angular Contact Ball Bearing

JAF/KYK Bearing No.	5300-ZZ
Bore diameter (d)	10 mm
Outer diameter (D)	35 mm
Basic Load Rating
Dynamic	1750 lbs
Static	1250 lbs
Speed Rating
Grease	11000 RPM

Weight	0.220 lbs
ABEC Rating	ABEC 1
Grease	Mobil Polyrex EM, 30-40% free volume fill
Radial Internal Clearance (C3)	+0.008 to -0.023 mm (+0.0003 to -0.0009 inch)
Tolerance
Inner Ring (d)	+0 to -0.008 mm (+0 to -0.0003 inch)
Outer Ring (D)	+0 to -0.01 mm (+0 to -0.0004 inch)
Width (W)	+0 to -0.12 mm (+0 to -0.0047 inch)

Made in Japan
