UCFL202-10S, 5/8" Bore 2-Bolt Flange Unit, X-Small Housing (0624)
$ 25.21
UCFL202-10S , Flange Mount Bearing, 2 Bolt Flange, Set Screw Locking, Bore 5/8" (15.875 mm)
Features:
Features:
- Standard duty unit, set screw locking
- Cast-iron housing
- Wide inner ring bearing
- Dual heavy-duty slinger type contact seals
- Set Screw Locking Extended Inner Race
Product Specifications
-
- INTERNAL RADIAL CLEARANCE: 0.011 - 0.025
- BORE DIAMETER: 5/8" (15.875mm)
- WIDTH MILLIMETERS: 57
- DYNAMIC LOAD RATING (N): 2878
- STATIC LOAD RATING (N): 1495
- MAXIMUM TEMPERATURE: 250 F
- CONSTRUCTION: Cast Iron
- BEARING MATERIAL: AISI 52100 Steel
- BEARING TYPE: Mounted Bearing Unit
- LOCKING TYPE: Set Screw
- INSERT: UC202-10S (40MM)
- OVERALL LENGTH: 99mm
- MOUNTING HOLE CENTER MILLIMETER: 76.5
- OVERALL WIDTH: 57mm
- OVERALL HEIGHT: 30.9mm
- BOLT HOLE SIZE: 3/8” / M10
- DESCRIPTION: 2 Bolt Flange - Wide Inner Ring Insert - Set Screw
- NUMBER OF BOLT Holes: 2
- MANUFACTURERS PART NUMBER: UCFL202-10S (40MM)
- MOUNTING SURFACE TO CENTERLINE OF SHAFT: 11mm
- Manufacturer: Tritan
-
