UCFL204-12, 3/4" 2-Bolt Flange Unit

$ 18.50


UCFL204-12, 3/4" 2-Bolt Flange Unit

  • Bore Dia. 3/4"
  • Bearing Insert Type Ball
  • Bearing Insert Material 52100 Chrome Steel
  • Locking Type Set Screw
  • Housing Material Cast Iron
  • Number of Bolts 2
  • Bolt Hole Size 3/8"
  • Bolt Hole Center-to-Center 90mm
  • Overall Height 33.3mm
  • Overall Width 60mm
  • Overall Length 113mm
  • Dynamic Load Capacity 2,878 lb.
  • Static Load Capacity 1,495. lb
  • Temp. Range -40 Degrees to 250 Degrees F
  • Finish Painted

Download the Specifications Sheet for this Series

•Cast iron F204 flange block housing increases life of the bearing •UC204-12 chrome steel bearing for efficient operations at a wide range of speeds •Dynamic (radial) load rating of 12.8 kN and static (axial) load rating of 6.65 kN •Set screw prevents shaft slippage •3/4" inside diameter fits conventional cylindrical shafts
