UCFL205-16, 1-0/0" 2-Bolt Flange Unit

• Bore Dia. 1"
• Bearing Insert Type Ball
• Bearing Insert Material 52100 Chrome Steel
• Locking Type Set Screw
• Housing Material Cast Iron
• Number of Bolts 2
• Bolt  Size 3/8"
• Bolt Hole Center-to-Center 99mm
• Overall Height 35.8mm
• Overall Width 68mm
• Overall Length 130mm
• Dynamic Load Capacity 3,147 lb.
• Static Load Capacity 1,765. lb
• Temp. Range -40 Degrees to 250 Degrees F
• Finish Painted

Download the Specifications Sheet for this Series

•Cast iron F205 flange block housing increases life of the bearing •UC205-16 chrome steel bearing for efficient operations at a wide range of speeds •Dynamic (radial) load rating of 14 kN and static (axial) load rating of 7.85 kN •Set screw prevents shaft slippage •1" inside diameter fits conventional cylindrical shafts
