UCFL207-23, 1-7/16" 2-Bolt Flange Unit

• Bore Dia. 1-7/16"
• Bearing Insert Type Ball
• Bearing Insert Material 52100 Chrome Steel
• Locking Type Set Screw
• Housing Material Cast Iron
• Number of Bolts 2
• Bolt Size 1/2"
• Bolt Hole Center-to-Center 130mm
• Overall Height 44.4mm
• Overall Width 90mm
• Overall Length 161mm
• Dynamic Load Capacity 5,778 lb.
• Static Load Capacity 3,440. lb
• Temp. Range -40 Degrees to 250 Degrees F
• Finish Painted

Download the Specifications Sheet for this Series

•Cast iron F207 flange block housing increases life of the bearing •UC207-23 chrome steel bearing for efficient operations at a wide range of speeds •Dynamic (radial) load rating of 25.7 kN and static (axial) load rating of 15.4 kN •Set screw prevents shaft slippage •1-7/16" inside diameter fits conventional cylindrical shafts
