UCFL207-35mm, 35mm 2-Bolt Flange Unit

• Bore Dia. 35mm
• Bearing Insert Type Ball
• Bearing Insert Material 52100 Chrome Steel
• Locking Type Set Screw
• Housing Material Cast Iron
• Number of Bolts 2
• Bolt Size 1/2"
• Bolt Hole Center-to-Center 130mm
• Overall Height 44.4mm
• Overall Width 90mm
• Overall Length 161mm
• Dynamic Load Capacity 5,778 lb.
• Static Load Capacity 3,440. lb
• Temp. Range -40 Degrees to 250 Degrees F
• Finish Painted

Download the Specifications Sheet for this Series

•Cast iron F207 flange block housing increases life of the bearing •UC207-35 chrome steel bearing for efficient operations at a wide range of speeds •Dynamic (radial) load rating of 25.7 kN and static (axial) load rating of 15.4 kN •Set screw prevents shaft slippage •35mm inside diameter fits conventional cylindrical shafts
