UCFL208-24, 1-1/2" 2-Bolt Flange Unit (0624)
$ 35.45
UCFL208-24, 1-1/2" 2-Bolt Flange Unit
- Bore Dia. 1-1/2"
- Bearing Insert Type Ball
- Bearing Insert Material 52100 Chrome Steel
- Locking Type Set Screw
- Housing Material Cast Iron
- Number of Bolts 2
- Bolt Size 1/2"
- Bolt Hole Center-to-Center 144mm
- Overall Height 51.2mm
- Overall Width 100mm
- Overall Length 175mm
- Dynamic Load Capacity 6,632 lb.
- Static Load Capacity 4,069. lb
- Temp. Range -40 Degrees to 250 Degrees F
- Finish Painted
Download the Specifications Sheet for this Series
•UCFL208-24 Oval Flange Pillow Block ( ISO 9001:2000 ) •Bearing Material: Chromium Steel ( Gcr15 ) •Housing Material: Cast Iron •Screw: Two set screw with Grease nipple **Load Rating (KN): Dynamic CR= 29500, Static Cor=18100
