UCFL209-28, 1-3/4" 2-Bolt Flange Unit (0624)

$ 50.21


UCFL209-28, 1-3/4" 2-Bolt Flange Unit

  • Bore Dia. 1-3/4"
  • Bearing Insert Type Ball
  • Bearing Insert Material 52100 Chrome Steel
  • Locking Type Set Screw
  • Housing Material Cast Iron
  • Number of Bolts 2
  • Bolt Size 5/8"
  • Bolt Hole Center-to-Center 148mm
  • Overall Height 52.2mm
  • Overall Width 108mm
  • Overall Length 188mm
  • Dynamic Load Capacity 5206 lb.
  • Static Load Capacity 4,631. lb
  • Temp. Range -40 Degrees to 250 Degrees F
  • Finish Painted

Download the Specifications Sheet for this Series
