7206-BMG-UA, ANGULAR CONTACT BALL BEARING, MACHINED BRONZE RETAINER, FLUSH GROUND, 40 DEGREE CONTACT ANGLE, CONSOLIDATED BRAND (1024)
7206-BMG-UA, ANGULAR CONTACT BALL BEARING, MACHINED BRONZE RETAINER, FLUSH GROUND, 40 DEGREE CONTACT ANGLE, CONSOLIDATED BRAND (1024)
7206-BMG-UA, ANGULAR CONTACT BALL BEARING, MACHINED BRONZE RETAINER, FLUSH GROUND, 40 DEGREE CONTACT ANGLE, CONSOLIDATED BRAND (1024)
7212-Bmg Consolidated Angular Contact Ball Bearing - None

7206-BMG-UA, ANGULAR CONTACT BALL BEARING, MACHINED BRONZE RETAINER, FLUSH GROUND, 40 DEGREE CONTACT ANGLE, CONSOLIDATED BRAND (1024)

$ 165.30


7206-BMG-UA
ANGULAR CONTACT BALL BEARING, BRONZE RETAINER, FLUSH GROUND 40 DEGREE CONTACT ANGLE, CONSOLIDATED BRAND

Dimensions & Data
d
30 mm
Bore diameter
D
62 mm
Outside diameter
B
16 mm
Width
Cr
23,100 N
Basic dynamic load rating, radial
C0r
14,100 N
Basic static load rating, radial
Cur
980 N
Fatigue load limit, radial
nG
15,800 RPM
Limiting speed
nϑr
11,200 RPM
Reference speed
≈m
0.205 kg
Weight
