99128 (ST128) Sturdi Shaft Repair Sleeve Kit

$ 11.02

Sold Out

For Shaft Size: 1.254" ~ 1.263",  Installed Width on Shaft: 0.315"

Sturdi Shaft Repair Kit: Includes Stainless Steel Sleeve, Installation Tool and Instructions. Individually Boxed

General Information
Type of Product: Sturdi Shaft Repair Sleeve Kit
Nominal Shaft Diameter: 1.260"
Width on Shaft: 5/16"
Construction Description: Ultra-thin wear sleeve made from stainless steel
Typical Application: Quick, easy, effective alternative to resizing, metallizing, or replacing a damaged surface. This repair sleeve has a high precision finish that is usually better than the original.
Shaft Range: 1.254" - 1.263"
Overall Width: 0.437"
"D" (Flange Diameter) For Sturdi Sleeve: 1.500"
Additional Features: Outside surface forms an ideal sealing surface without the need for additional surface preparation. Fast shaft repair with included installation tool, often without changing the current seal. Tools required for installation: Mallet and pliers.
Brand Name: STURDI
Weight Ea. (Lbs): 0.132
Feature: Excessive water, dirt, heat, lack of lubrication or high shaft speed can all cause a sealing lip to groove the shaft and ultimately create a leak. When a new seal cannot compensate for excessive damage in small diameter shafts, select a Sturdi-Sleeve. This ultra-thin wear sleeve provides a snug, leak-proof fit on shafts. It is so thin that you can use the same seal size. Sturdi-Sleeve is the cost-effective alternative to machining, metallizing or replacing the severely damaged surface • It installs easily, with minimal machine downtime.
