> Products > 319 Timken Tapered Roller Bearing Cone (0726)
319 Timken Tapered Roller Bearing Cone (0726)
319 Timken Tapered Roller Bearing Cone (0726)
319 Timken Tapered Roller Bearing Cone (0726)

319 Timken Tapered Roller Bearing Cone (0726)

$ 74.90

Cone Part Number

 319

Bore (d)

 1.1811 in. / 30 mm

Inner Ring Width (B)

 0.8730 in. / 22.174 mm
Dynamic Radial Load Rating - 1M Revs (C1) 1 16800 lbf. / 74900 N
Dynamic Radial Load Rating - 90M Revs (C90) 2 4370 lbf. / 19400 N
K Factor 3 2.32



Other Dimensions

Weight

 1 lb. / 0.5 Kg
Effective Center Location4 -0.27 in. / -6.9 mm
Max Shaft Fillet Radius5 0.03 in. / 0.760 mm

Shaft Backing Shoulder Diameter - Frontface (da)

 1.42 in. / 36 mm

Shaft Backing Shoulder Diameter - Backface (db)

 1.46 in. / 37 mm

Cage Location rel. to BF (Aa)

 0.01 in. / 0.3 mm

Cage Location rel. to FF (Ab)

 0.04 in. / 1 mm

Ratings

Dynamic Axial Rating - 90M Revs (Ca90)6 1880 lbf. / 8370 N

Static Radial Load Rating (CO)

 16800 lbf. / 74800 N



Factors

G1 Factor

 20.3

G2 Factor

 7.9
Geometry Factor (Cg)7 0.0602



  • 1 Based on 1 x 106 revolutions L10 life, for the ISO life calculation method.
  • 2 Based on 90 x 106 revolutions L10 life, for The Timken Company life calculation method. C90 and Ca90 are radial and thrust values.
  • 3 These factors apply for both inch and metric calculations. Consult your Timken representative for instruction on use.
  • 4 Negative value indicates effective center inside cone backface.
  • 5 These maximum fillet radii will be cleared by the bearing corners.
  • 6 Based on 90 x 106 revolutions L10 life, for The Timken Company life calculation method. C90 and Ca90 are radial and thrust values for a single-row, C90(2) is the two-row radial value.
  • 7 Geometry constant for Lubrication Life Adjustment Factor a3l.
