33115, ZNL Brand, Tapered Roller Bearing Set (0926)

$ 68.70

Key Dimensions

Cone Part Number	X33115M
Cup Part Number	Y33115M
Bore (d)	75 mm 2.9528 in
O.D. (D)	125 mm 4.9213 in
Width (T)	37 mm 1.4567 in
Dynamic Radial Load Rating - 1M Revs (C1) ¹	205000 N 46000 lbf
Dynamic Radial Load Rating - 90M Revs (C90) ²	53000 N 11900 lbf
e Factor ³	0.4
K Factor ⁴	1.47
Series	33115
Y Factor ⁵	1.51

Other Dimensions

Inner Ring Width (B)	37.000 mm 1.4567 in
Outer Ring Width (C)	29 mm 1.1417 in
Effective Center Location⁶	-7.4 mm -0.29 in
Max Shaft Fillet Radius⁷	2.030 mm 0.080 in
Max Housing Fillet Radius⁸	1.52 mm 0.06 in
Shaft Backing Shoulder Diameter - Frontface (da)	83 mm 3.27 in
Shaft Backing Shoulder Diameter - Backface (db)	88 mm 3.46 in
Housing Backing Shoulder Diameter - Frontface (Da)	119.90 mm 4.75 in
Housing Backing Shoulder Diameter - Backface (Db)	112.01 mm 4.41 in
Cage Location Relative to Backface (Aa)	2.3 mm 0.09 in
Cage Location Relative to Frontface (Ab)	3 mm 0.12 in
Weight	1.80 Kg 3.9 lb

Ratings

Dynamic Axial Rating - 90M Revs (Ca90)⁹	36100 N 8110 lbf
Static Radial Load Rating (C0)	287000 N 64500 lbf

Factors

G1 Factor	110.7
G2 Factor	26.3
Geometry Factor (Cg)¹⁰	0.0851
